SS 304 AISI Stainless Steel Plate width 1000mm
Stainless Steel Flat Sheet is a popular and versatile metal that offers good corrosion resistance to numerous chemicals. It’s used in a variety of applications including construction, marine and the food industry.
Stainless Steel Flat Sheet is measured by its thickness in inches or mm.
Stainless Steel Flat Sheet cross section
Stainless Steel Flat Sheet 304 is a flat shaped sheet of 304 stainless steel alloy.
304 has excellent mechanical properties, resistance to many corrosive agents.
304 Stainless Steel is useful where sanitation and cleanliness are important.
Details:
ITEM | Stainless Steel Coils |
Thickness | 0.01-15.0mm or Customized |
Width | 10-1500mm or Customized |
Coil weight | 3-8 Tons |
MOQ | 3 Tons |
Technique | Hot rolled/Cold Rolled |
Brand | TISCO, LISCO, ZPSS, BAOSTEEL |
Material Grade |
201.202.301.302.304.304L.310S.316.316L.321.347,329,A.309S.2205.2507.2520. 430.410.440.904Lect. Or Customized |
Standard | GB, AISI, ASTM, ASME, EN, BS, DIN, JIS |
Surface | 2B.NO.1.,NO.3,NO.4,HL,BA,8K,Matte, Satin,Gold Titanium Or customized; |
Application | Foodstuff, Gas, metallurgy, biology, electron, chemical, petroleum, boiler, nuclear energy, Medical equipment, fertilizer etc |
Package | Standard export sea-worthy packing or customized |
Lead Time | 3-15 days after deposit |
Payment | TT/LC |
Sample | we could offer the sample for free charge but do not pay the cost of freight. |
Tensile Strength | ≥75ksi or ≥515MPa |
Yield Strength | ≥30ksi or ≥205MPa |
Elongation in 2inch,or50mm | ≥40% |
Hardness | ≤201HBW or ≤92HRB |
Carbon | ≤0.03% |
Manganese | ≤2.00% |
Phosphorus | ≤0.045% |
Sulfur | ≤0.030% |
Silicon | ≤0.75% |
Chromium | 17.5%-19.5% |
Nickel | 8.0%-12.0% |
Nitrogen | ≤0.10% |
Magnetic or not | Nonmagnetic |
Thickness | Allowable deviation | Width | ||
Up(mm) | Down(mm) | ≤1000(mm) | >1000~≤1300(mm) | |
0.10 | 0.03 | 0.03 | ||
0.20 | 0.05 | 0.05 | ||
0.30 | 0.03 | --- | ||
0.40 | 0.04 | 0.04 | ||
0.50 | 0.08 | 0.08 | ||
0.60 | 0.05 | 0.05 | ||
0.80 | 0.05 | 0.05 | ||
1.00 | 0.13 | 0.13 | ||
1.00 | 0.055 | 0.06 | ||
2.00 | 0.18 | 0.18 | ||
2.00 | 0.10 | 0.10 | ||
3.00 | 0.25 | 0.25 | ||
3.00 | 0.13 | 0.13 | ||
4.00 | 0.36 | 0.36 | ||
5.00 | 0.17 | 0.17 | ||
6.00 | 0.17 | 0.20 | ||
8.00 | 0.17 | 0.22 |
FAQ A: How could I get a sample? Samples are free.Before we received the first order, please afford the express fee. We will return the express fee back to you within your first order. B:what can you buy from us? Stainless Steel pipe,Stainless Steel coil,Stainless Steel sheet,Stainless Steel bar,stainless steel elbow . C: Whether you could make our brand on your products? Yes. We can print your Logo on both the products and the packages if you can meet our MOQ. D: Whether you could make your products by our color? Yes, The color of products can be customized if you can meet our MOQ. E; How to guarantee the quality of your products? 1) Strict detection during production. 2) Strict sampling inspection on products before shipment and intact product packaging ensured. |
