DX51D+Z120 Galvanized Steel Plate Coil Sheets 0.3*1250MM THK BS EN 10327 Big Spangle

DX51D+Z120 Galvanized Steel Plate Coil Sheets 0.3*1250MM THK BS EN 10327 Big Spangle

Products - Galvanized Steel Plate
  • High Light

    DX51D+Z120 galvanized steel plate

    ,

    0.3mm galvanized steel plate

    ,

    DX51D+Z120 galvanized plate

  • Application
    Construction/Shipbuilding/Boiler
  • Coil Weight
    3-8 MT Per Coil
  • Grade
    SGCC/SGCH/DX51D+Z
  • Length
    1000mm-6000mm
  • Material
    Galvanized Steel
  • Package
    Standard Seaworthy Export Package
  • Spangle
    Regular/Minimized/Zero
  • Special Use
    High-strength Steel Plate
  • Surface Finish
    Regular Spangle/Chromate-free Passivation
  • Surface Treatment
    Galvanized
  • Technique
    Cold Rolled
  • Thickness
    0.2mm-3.0mm
  • Width
    600mm-1500mm
  • Zinc Coating
    40g-275g/m2
  • Place of Origin
    China
  • Brand Name
    Baosteel
  • Certification
    BS EN10327
  • Model Number
    DX51D+Z120
  • Minimum Order Quantity
    5 Ton
  • Price
    USD400-590/Ton
  • Packaging Details
    Export packaging + binding tape
  • Delivery Time
    5-8 work days
  • Supply Ability
    1000Ton/Month

DX51D+Z120 Galvanized Steel Plate Coil Sheets 0.3*1250MM THK BS EN 10327 Big Spangle

  • DX51D+Z120 Galvanized Steel Plate Coil Sheets 0.3*1250MM THK BS EN 10327 Big Spangle
  • DX51D+Z120 Galvanized Steel Plate Coil Sheets 0.3*1250MM THK BS EN 10327 Big Spangle
  • DX51D+Z120 Galvanized Steel Plate Coil Sheets 0.3*1250MM THK BS EN 10327 Big Spangle
  • DX51D+Z120 Galvanized Steel Plate Coil Sheets 0.3*1250MM THK BS EN 10327 Big Spangle
  • DX51D+Z120 Galvanized Steel Plate Coil Sheets 0.3*1250MM THK BS EN 10327 Big Spangle
  • DX51D+Z120 Galvanized Steel Plate Coil Sheets 0.3*1250MM THK BS EN 10327 Big Spangle
Get Price Contact Now

DX51D+Z120 0.3MM THK Galvanized Steel Sheets BS EN 10327 Big Spangle



The main performance and use of DX51D+Z120 0.3mm thick galvanized steel sheets with a big spangle can be described as follows:

1. Corrosion Resistance: The zinc coating on DX51D+Z120 galvanized steel sheets provides excellent corrosion resistance, making them suitable for outdoor applications that are exposed to moisture, humidity, and other corrosive elements. This makes them ideal for roofing, siding, and other construction applications where durability and long-term protection are required.

2. Strength and Durability: DX51D+Z120 galvanized steel sheets are known for their high tensile strength and structural integrity. They can withstand heavy loads, making them suitable for use in structural components, such as beams, columns, and trusses in construction projects.

3. Aesthetic Appeal: The big spangle pattern on these galvanized steel sheets adds an attractive and decorative element to their appearance. This makes them suitable for architectural applications where aesthetics are important, such as for cladding, facades, and interior design elements.

4. Formability and Workability: DX51D+Z120 galvanized steel sheets can be easily formed and manipulated through processes like cutting, bending, and welding. This allows for customization and adaptation to specific design requirements, making them versatile for a wide range of applications.

5. Cost-Effectiveness: Galvanized steel sheets are cost-effective compared to other materials with similar corrosion resistance properties. The initial investment in galvanized steel sheets is relatively low, and their long lifespan and low maintenance requirements contribute to overall cost savings.



Some common uses of DX51D+Z120 0.3mm thick galvanized steel sheets with a big spangle include:

- Roofing and siding in residential, commercial, and industrial construction projects.
- Cladding and decorative elements in architectural applications.
- Structural components in buildings and infrastructure.
- Automotive parts, such as body panels and chassis components.
- Appliances, such as refrigerators, washing machines, and ovens.
- Manufacturing and fabrication applications, including metal furniture, storage containers, and electrical enclosures.



Overall, DX51D+Z120 0.3mm thick galvanized steel sheets with a big spangle offer excellent corrosion resistance, strength, aesthetic appeal, formability, and cost-effectiveness. They find extensive use in various industries due to their versatile properties and wide range of applications.



DX51D+Z120 Chemical composition analysis
Carbon ≤0.12%
Silicon ≤0.50%
Manganese ≤0.60%
Phosphorus ≤0.10%
sulfur ≤0.045%

Titanium

 ≤0.30%
Zinc layer ≥120g/㎡



Mechanical property
Tensile strength 270-500 MPa
Elongation ≥22%

DX51D+Z120 Galvanized Steel Plate Coil Sheets 0.3*1250MM THK BS EN 10327 Big Spangle 0

DX51D+Z120 Galvanized Steel Plate Coil Sheets 0.3*1250MM THK BS EN 10327 Big Spangle 1DX51D+Z120 Galvanized Steel Plate Coil Sheets 0.3*1250MM THK BS EN 10327 Big Spangle 2

FAQ

Q1: What does DX51D+Z120 mean?
A1: DX51D is the designation for the steel grade, which specifies its chemical composition and mechanical properties. Z120 refers to the zinc coating weight, indicating that the galvanized steel sheets have a coating weight of 120 grams per square meter.



Q2: What is the significance of the big spangle pattern?
A2: The big spangle pattern on the galvanized steel sheets refers to the size of the crystalline pattern that forms on the surface of the zinc coating during the galvanization process. It adds an aesthetic appeal and can be visually appealing for architectural and decorative applications.



Q3: How does the zinc coating provide corrosion resistance?
A3: The zinc coating acts as a sacrificial anode, protecting the underlying steel from corrosion. Zinc has a higher electrochemical potential than steel, so it corrodes preferentially, sacrificing itself to protect the steel beneath from exposure to moisture and oxidation.



Q4: What are the typical applications for DX51D+Z120 galvanized steel sheets with a big spangle?
A4: These galvanized steel sheets are commonly used in roofing, siding, cladding, architectural elements, structural components, automotive parts, appliances, and various manufacturing applications. They provide corrosion resistance, strength, and aesthetic appeal in these diverse industries.



Q5: Can DX51D+Z120 galvanized steel sheets with a big spangle be customized in terms of size and thickness?
A5: Yes, galvanized steel sheets can be customized to meet specific size and thickness requirements. Manufacturers can provide different dimensions based on customer needs, allowing for flexibility in design and application.



Q6: How are DX51D+Z120 galvanized steel sheets with a big spangle fabricated or processed?
A6: These galvanized steel sheets can be easily cut, bent, formed, and welded using standard metal fabrication techniques. This allows for easy customization and adaptation to specific design requirements.



Q7: Are DX51D+Z120 galvanized steel sheets cost-effective compared to other materials?
A7: Yes, galvanized steel sheets are generally considered cost-effective due to their long lifespan, low maintenance requirements, and competitive pricing compared to other corrosion-resistant materials. The initial investment is relatively low, and the durability of galvanized steel sheets contributes to long-term cost savings.



Q8: Are there any limitations or precautions when using DX51D+Z120 galvanized steel sheets with a big spangle?
A8: While galvanized steel sheets offer excellent corrosion resistance, it is important to ensure proper installation and maintenance to maximize their lifespan. It is also advisable to consider the specific environment and application requirements to choose the appropriate thickness and grade of galvanized steel sheets.
