SS 304 AISI Stainless Steel Plate width 1000mm
Product Description of 304 stainless steel plate
Stainless Steel Flat Sheet is a popular and versatile metal that offers good corrosion resistance to numerous chemicals. It’s used in a variety of applications including construction, marine and the food industry.
Stainless Steel Flat Sheet is measured by its thickness in inches or mm.
Stainless Steel Flat Sheet cross section
Stainless Steel Flat Sheet 304 is a flat shaped sheet of 304 stainless steel alloy.
304 has excellent mechanical properties, resistance to many corrosive agents.
304 Stainless Steel is useful where sanitation and cleanliness are important.
Details of 304 stainless steel plate:
| ITEM | Stainless Steel Coils |
| Thickness | 0.01-15.0mm or Customized |
| Width | 10-1500mm or Customized |
| Coil weight | 3-8 Tons |
| MOQ | 3 Tons |
| Technique | Hot rolled/Cold Rolled |
| Brand | TISCO, LISCO, ZPSS, BAOSTEEL |
| Material Grade |
201.202.301.302.304.304L.310S.316.316L.321.347,329,A.309S.2205.2507.2520. 430.410.440.904Lect. Or Customized |
| Standard | GB, AISI, ASTM, ASME, EN, BS, DIN, JIS |
| Surface | 2B.NO.1.,NO.3,NO.4,HL,BA,8K,Matte, Satin,Gold Titanium Or customized; |
| Application | Foodstuff, Gas, metallurgy, biology, electron, chemical, petroleum, boiler, nuclear energy, Medical equipment, fertilizer etc |
| Package | Standard export sea-worthy packing or customized |
| Lead Time | 3-15 days after deposit |
| Payment | TT/LC |
| Sample | we could offer the sample for free charge but do not pay the cost of freight. |
| Tensile Strength | ≥75ksi or ≥515MPa |
| Yield Strength | ≥30ksi or ≥205MPa |
| Elongation in 2inch,or50mm | ≥40% |
| Hardness | ≤201HBW or ≤92HRB |
| Carbon | ≤0.03% |
| Manganese | ≤2.00% |
| Phosphorus | ≤0.045% |
| Sulfur | ≤0.030% |
| Silicon | ≤0.75% |
| Chromium | 17.5%-19.5% |
| Nickel | 8.0%-12.0% |
| Nitrogen | ≤0.10% |
| Magnetic or not | Nonmagnetic |
| Thickness | Allowable deviation | Width | ||
| Up(mm) | Down(mm) | ≤1000(mm) | >1000~≤1300(mm) | |
| 0.10 | 0.03 | 0.03 | ||
| 0.20 | 0.05 | 0.05 | ||
| 0.30 | 0.03 | --- | ||
| 0.40 | 0.04 | 0.04 | ||
| 0.50 | 0.08 | 0.08 | ||
| 0.60 | 0.05 | 0.05 | ||
| 0.80 | 0.05 | 0.05 | ||
| 1.00 | 0.13 | 0.13 | ||
| 1.00 | 0.055 | 0.06 | ||
| 2.00 | 0.18 | 0.18 | ||
| 2.00 | 0.10 | 0.10 | ||
| 3.00 | 0.25 | 0.25 | ||
| 3.00 | 0.13 | 0.13 | ||
| 4.00 | 0.36 | 0.36 | ||
| 5.00 | 0.17 | 0.17 | ||
| 6.00 | 0.17 | 0.20 | ||
| 8.00 | 0.17 | 0.22 | ||
Surface Treatment
| Surface Treatment | Definition | Application |
| NO.1 | A hot - rolled piece whose surface has been treated by heat treatment, pickling or the corresponding process | Chemical Tanks, Pipes, Chemical Industry Equipment etc. |
| 2B | After cold rolling, heat treatment, pickling or other equivalent treatment, the final cold rolling to give appropriate luster | Medical Equipment, Food Industry, Construction Material, Kitchen Utensils etc. |
| BA | After cold rolling, bright heat treatment is given | Kitchen Utensils, Electric Equipment, Building Construction etc. |
| NO.4 | Products polished with abrasives 150 to 180 as specified in JIS R6001 | Kitchen Utensils, Building Construction, Medical Equipment etc. |
| HL | After polishing, use the appropriate abrasive size to form a continuous polishing streak | Building Construction etc. |
| 8K | A mirror-like reflective surface given by polishing with finer abrasives over 800 mesh | Reflector, Mirror, Interior and exterior decoration etc. |
